Description
- Custom High-Precision Filament：Create filaments with custom colors, and materials Waste Recycling：Recycle all 3D printing waste (finished/failed prints, supports, Brim、skirts) Material R&D：Conduct blending experiments Develop innovative composites and functional filaments Professional Use：Aerospace: Small-batch high-strength specialty filaments Medical/Education: Biocompatible or educational materials
Core Specifications Parameter Value Body Material High-strength structural steel +Aluminum alloy+ plastics Dimensions 480×480×200 mm Weight 13 kg Production Rate 400 g/h（Approximately 2.5m/min） Temperature Range Ambient–400°C Max Power 500 W Cruising Power 200 W Power Consumption 0.5 kWh/kg (per kilogram of filament) Screw Material Nitrided alloy steel (HRC58-65) Additional Notes: Power Supply: AC 110V/220V (50/60Hz) Filament Diameter: 1.75 mm Supported Materials: PLA, ABS, PETG, TPU, PET, PP, PS, PA, Nylon, PC, PVA, PEEK、etc. 4.3” Touchscreen: Real-time monitoring of temperature, diameter, and progress Spooling System: Auto-speed adjustment, compatible with spools ≤110mm wide, ≤280mm diameter Auto-Shutdown: Stops heating、motors、fan at preset time/length Design Notes: Precision: ≤0.03 mm for virgin materials, ≤0.04 mm for recycled materials. Sensor: 3DPANY Laser Diameter Sensor (500 scans/sec). Control System: Closed-loop control + AI Diameter Compensation.
