Precision FTIR Spectrometer with Attenuated Total Reflection Capability
This laboratory-grade infrared spectrophotometer delivers high-resolution FTIR performance across a broad
wavenumber range using Attenuated Total Reflection (ATR) technology. Engineered with a precision-machined optical bench,
internal dynamic collimation, and user-replaceable components, it provides outstanding repeatability and stability in analytical,
academic, and R&D settings. The integrated cube-corner optics minimize alignment needs, while the containerized desiccant system
protects beam splitters from moisture degradation.
Key Features
- Integrated Optical Bench: Cast aluminum design ensures long-term stability
- Dynamic Collimation: Movable mirror and voice coil driver keep the interferometer in optimal condition
- ATR Enabled: Compatible with attenuated total reflection methods for surface analysis
- User-Serviceable: Modular design with easily replaceable components and reduced maintenance needs
- High Stability: Designed to operate reliably in harsh lab environments
Specifications Table
| Wavenumber Range | 7800 – 375 cm⁻¹ |
| Resolution | 1 cm⁻¹ |
| S/N Ratio | 30,000:1 (DTGS @ 4 cm⁻¹, 1 min scan at 2100 cm⁻¹) |
| Detector Type | DTGS (High Resolution) |
| Beamsplitter | Coated KBr |
| Light Source | Long-life air-cooled IR source |
| A/D Conversion | 24-bit, 500 MHz |
| Connectivity | USB 2.0 |
| Power Supply | 110–220V AC, 50–60 Hz |
