Description
Description
Portable AC/DC simulator designed for commissioning and diagnostic testing of public EV charging stations. Emulates CCS2; Type 2; and CHAdeMO protocols; providing real-time measurements of voltage; current; and communication signals in a single handheld unit.
Key Features
- Simulates CCS2; Type 2; CHAdeMO connectors
- Supports DC up to 1000 V and AC up to 22 kW
- Large LCD display with oscilloscope mode
- Stores test logs to removable SD card
- Rechargeable Li-ion battery for field use
Specifications Table
| Supported Interfaces | CCS2; Type 2; CHAdeMO |
|---|---|
| DC Voltage Range | 0-1000 V |
| AC Power Range | Up to 22 kW |
| Data Logging | SD Card |
| Display | Color LCD |
