Description
This 48V LiFePO Power Wall provides 10kWh of deep-cycle energy storage with a 51.2V nominal voltage and 100Ah capacity. Designed for high-performance solar systems; it offers over 6000 charging cycles at 80% DOD and a service life exceeding 15 years. Equipped with a BMS for automatic protection; it supports safe operation in demanding environments and includes internal cell balancing; lightweight construction; and self-cooling design. This unit is maintenance-free and supports both series and parallel configurations; making it ideal for residential and light commercial installations.
Key Features
- 10kWh total capacity with 100Ah at 51.2V nominal
- Built-in Battery Management System (BMS) with overcharge; discharge; overcurrent; and thermal protection
- Service life >15 years at 25C with over 6000 cycles
- Supports CAN communication and most inverter brands
- Maintenance-free design with internal battery balancing
- Lightweight housing approximately 40%50% less than lead-acid
- Wide temperature range: -20C to 60C
Specifications Table
| Nominal Voltage | 51.2V |
| Capacity | 100Ah |
| Total Energy | 10kWh |
| Battery Type | LiFePO |
| Cycle Life | >6000 cycles |
| Communication | CAN; RS485 |
| Service Life | >15 years |
| Cooling Method | Self-cooling |
